Soundproofing Movable Partition Wall with STC Rating 42-56dB and 304 Stainless Steel for Church Applications

Marchio:	AE
Numero di modello:	AE100
Moq:	10 metri quadrati
prezzo:	USD 90-135 Per Square Meter
Condizioni di pagamento:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Capacità di fornitura:	1000 metri quadrati al mese

Informazioni dettagliate

Descrizione del prodotto

Informazioni dettagliate

Luogo di origine:

Guangdong, Cina

Certificazione:

ISO9001 SGS

Nome prodotto:

Parete divisoria mobile scorrevole

Applicazione:

La divisione della Chiesa

Conformità::

Sala riunioni, scuola

Spessore:

105 cm

Classificazione STC:

42-56 dB

Dimensioni:

Personalizzazione (altezza: fino a 18 M, larghezza per pannello: fino a 1,2 M)

Imballaggi particolari:

strato di schiuma e cartone duro con custodia in compensato o pallet in acciaio

Evidenziare:

Soundproofing Movable Partition Wall

STC Rating 42-56dB Sliding Partition Wall

304 Stainless Steel Temporary Wall Divider

Descrizione del prodotto

Temporary Movable Sliding Partition Wall Soundproofing For Office

Customization Sliding Walls Movable Partition Wall Soundproofing for Office

A temporary movable wall divider comprises multiple partitions that glide effortlessly along a track. Each divider typically ranges from 60 to 120 cm in width, while height varies based on specific requirements. Structurally akin to assembled movable partitions, these dividers offer flexibility and functionality in various settings.

There are two main types of temporary movable wall dividers: sliding and sliding-up. Sliding dividers feature pulleys at the base, guided by trough-type rails embedded in both the ceiling and floor, ideal for heavy-duty applications. Conversely, sliding-up dividers employ sets of pulleys at the top of each partition, enabling smooth movement along tracks. Options such as L-shaped, T-shaped, or cross-shaped rails allow partitions to change direction, dividing expansive spaces into smaller, versatile areas.

Operable by hand or powered mechanisms based on weight and width, these partitions can be stacked to the sides or stored when not in use. Their ability to create smaller indoor spaces significantly reduces central air conditioning energy consumption. Offering flexibility in spatial configuration, these dividers streamline interior decoration and partitioning processes, maintaining cleanliness and efficiency throughout.

High-Quality Service Commitment:

Our products are certified by SGS and ILAC-MRA, ensuring reliable performance.
We combine leading German partition technology to provide global professional space solutions.
Extend the lifespan of your professional products, ensuring long-term performance stability.
Provide quick follow-up and transparent quoting services to meet your needs.
Offer on-site inspection services to ensure quality and accuracy during project implementation.
We promise punctual delivery to ensure smooth project progress according to schedule.

Unique Roller Options & Features:

Utilizes Dupont POM rollers for optimal performance.
Crafted from 304 stainless steel with heavy-duty capabilities, incorporating safety features and precision CNC machining.
Patented wheel design ensures effortless operation of the entire movable partition system.

Specification

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS

Series	Element thickness	Element width* (min./max.)	Clear height* (min./max.)	Framed construction	Panel fixing	Element interconnection/design of the vertical profiles
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight
