Portable Soundproof Movable Partition Wall with Dupont POM Rollers and Top and Bottom Jack Lifting

Name: Portable Soundproof Movable Partition Wall with Dupont POM Rollers and Top and Bottom Jack Lifting
Brand: FOSHAN AE PARTITION TECHNOLOGY LIMITED COMPANY
SKU: AE100
Price: 107.00 USD
Availability: InStock

Marchio:	AE
Numero di modello:	AE100
Moq:	10 metri quadrati
prezzo:	USD 90-125 Per Square Meter
Condizioni di pagamento:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Capacità di fornitura:	1000 metri quadrati al mese

Informazioni dettagliate

Descrizione del prodotto

Informazioni dettagliate

Luogo di origine:

Guangdong, Cina

Certificazione:

ISO9001 SGS

Modello:

AE100 Parete divisoria mobile

Opzione di finitura:

BORDO A PROVA DI FUOCO

Conformità:

Sala riunioni, scuola

Spessore:

105 cm

Classificazione STC:

42-56 dB

Dimensioni:

Personalizzazione (altezza: fino a 18 M, larghezza per pannello: fino a 1,2 M)

Nome:

Parete divisoria mobile

Imballaggi particolari:

strato di schiuma e cartone duro con custodia in compensato o pallet in acciaio

Evidenziare:

Dupont POM Rollers Movable Partition Wall

Top and Bottom Jack Lifting Folding Partition Wall

Magnetic Seal Operable Partition Wall

Descrizione del prodotto

Design Portable Movable Partition Wall Soundproof Folding Hotel Room

Our high-quality, custom Movable Partition Wall systems combine ease of installation with elegant design. Designed for simplicity, reusability, and cost-effectiveness, our partitions offer comprehensive features including bridging, panels, doors, and windows.

Key Features

Customizable finishes with options for corner channels, soundproof blankets, and cavity insulation
Panel thickness options from 65mm to 100mm, accommodating heights up to 40'
Excellent sound control with STC ratings up to 53
User-friendly design with comprehensive installation training
Non-intrusive construction with flexible wiring and plumbing options

Quality Assurance

SGS and ILAC-MRA certified products
Incorporates leading German partition technology
Extended product lifespan with stable long-term performance
Quick follow-up and transparent quoting services
On-site inspection services for quality assurance
Punctual delivery to ensure project timelines

Roller System Features

Dupont POM rollers for optimal performance
304 stainless steel construction with heavy-duty capabilities
Precision CNC machining with safety features
Patented wheel design for effortless operation

Panel Specifications

100mm thickness for enhanced stability and sound insulation
Diverse range of acoustical and decorative finishes
Robust 6061-T6 profile with Q235 steel frame
Top and bottom jack lifting mechanisms (800N sealing power)
Magnetic seal with 40N/m attraction for secure closure

Technical Specifications

Series	Element Thickness (mm)	Element Width (min/max mm)	Clear Height (min/max mm)	Construction	Panel Fixing	Element Interconnection
AE65	65	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	85	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	100	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology: Weighted sound reduction value (Rw): 52/56 dB (GB/T19889.3-2005)
Connection System: Convex-concave profile form with 40 N/m magnetic attraction
* Larger widths available upon request. Final dimensions subject to Design Department approval.
